004641024
CE07.10-400V-50/60Hz Miniature motor contactor
- ETI Code:
- 004641024
- Number of poles:
- 3
- Rated operation current Ie at AC1:
- 16 A
- Rated operation current Ie at AC3, 400V:
- 7 A
- Rated operational voltage (AC):
- 400 V
- Rated control circuit voltage Uc (AC):
- 400 V
- No. of NO contacts:
- 3
- No. of aux NO contacts:
- 1
- Function:
- Miniature contactors
- Catalogue Group:
- Miniature and auxiliary contactor CE, CAE, CE17
14 Logistics
Product
- Net weight of the product
- 0.12 kg
- Net width
- 45.5 mm
- Net height
- 42.3 mm
- Net depth
- 44.26 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 1 pcs
- EAN code for a transport packaging
- 7890355107843
- Transport packaging weight
- 0.13 kg
- Transport Packaging Dimensions Height
- 50 mm
- Transport Packaging Dimensions Width
- 47 mm
- Transport Packaging Dimensions Depth
- 47 mm
- Transport packaging volume
- 0.11 dm³
- Pallet quantity
- 6,667 pcs
- Customs tariff
- 85364900
11 ETIM
- Rated operation current Ie at AC-3, 400 V
- 7 A
- Voltage type for actuating
- AC
- Type of electrical connection of main circuit
- Frame clamp
- Number of normally open contacts as main contact
- 3
- Number of auxiliary contacts as normally open contact
- 1
- Rated operation power at AC-3, 400 V
- 3 kW
- Rated operation current Ie at AC-1, 400 V
- 16 A
- Rated control supply voltage AC 60 Hz(Min)
- 400 V
- Rated control supply voltage AC 50 Hz(Min)
- 400 V
- Rated control supply voltage AC 60 Hz(Max)
- 400 V
- Rated control supply voltage AC 50 Hz(Max)
- 400 V
ETIM Classification – Version 9.0
