004641149
CEC016.10 110V-DC Miniature motor contactor
- ETI Code:
- 004641149
- Number of poles:
- 3
- DC rated control supply voltage Uc:
- 110 V
- Rated operation current Ie at AC1:
- 22 A
- Rated operation current Ie at AC3, 400V:
- 16 A
- Rated operational voltage (AC):
- 690 V
- Rated control circuit voltage Uc (DC):
- 110 V
- No. of NO contacts:
- 3
- No. of aux NO contacts:
- 1
- Function:
- Miniature contactors
- Catalogue Group:
- Miniature contactor CEC
14 Logistics
Product
- Net weight of the product
- 0.218 kg
- Net width
- 45.5 mm
- Net height
- 58 mm
- Net depth
- 52.02 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 1 pcs
- EAN code for a transport packaging
- 7890355552391
- Transport packaging weight
- 0.229 kg
- Transport Packaging Dimensions Height
- 61 mm
- Transport Packaging Dimensions Width
- 48.5 mm
- Transport Packaging Dimensions Depth
- 55 mm
- Transport packaging volume
- 0.163 dm³
- Pallet quantity
- 3,200 pcs
- Customs tariff
- 85364900
9 ETIM
- Rated operation current Ie at AC-3, 400 V
- 18.7 A
- Voltage type for actuating
- DC
- Type of electrical connection of main circuit
- Frame clamp
- Number of normally open contacts as main contact
- 3
- Number of auxiliary contacts as normally open contact
- 1
- Rated operation power at AC-3, 400 V
- 7.5 kW
- Rated operation current Ie at AC-1, 400 V
- 22 A
- Rated control supply voltage DC(Min)
- 110 V
- Rated control supply voltage DC(Max)
- 110 V
ETIM Classification – Version 9.0
