004641172
CECA0.13-220V-DC Aux.contactor
- ETI Code:
- 004641172
- Number of poles:
- 4
- DC rated control supply voltage Uc:
- 220 V
- Rated operation current Ie at AC1:
- 10 A
- Rated operational voltage (AC):
- 230 V
- Rated control circuit voltage Uc (DC):
- 220 V
- No. of aux NO contacts:
- 1
- No. of aux NC contacts:
- 3
- Function:
- Auxiliary contactors
- Catalogue Group:
- Accessories CEC
5 Documents
14 Logistics
Product
- Net weight of the product
- 0.218 kg
- Net width
- 45.5 mm
- Net height
- 58 mm
- Net depth
- 52.02 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 1 pcs
- EAN code for a transport packaging
- 7890355552773
- Transport packaging weight
- 0.229 kg
- Transport Packaging Dimensions Height
- 61 mm
- Transport Packaging Dimensions Width
- 48.5 mm
- Transport Packaging Dimensions Depth
- 55 mm
- Transport packaging volume
- 0.163 dm³
- Pallet quantity
- 3,478 pcs
- Customs tariff
- 85364900
7 ETIM
- Rated operation current Ie, 400 V
- 10 A
- Voltage type for actuating
- DC
- Connection type auxiliary circuit
- Screw connection
- Number of auxiliary contacts as normally open contact
- 1
- Number of auxiliary contacts as normally closed contact
- 3
- Rated control supply voltage DC(Min)
- 220 V
- Rated control supply voltage DC(Max)
- 220 V
ETIM Classification – Version 9.0
1 Diagrams
1 Software & drivers
Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
23 Tags
004641172Aux.contactorCECA0.13-220V-DCETICONMiniature contactorsMiniature contactor relayMiniature contactor relayCECA0CECA0InternationalContactors ETICONMiniature and auxilary contactors and acessoriesMiniature and auxilary contactorsRated control circuit voltage Uc (DC): 220 VNo. of NC contacts: 0Rated operational voltage (AC): 230 VNo. of aux NC contacts: 3Function: Auxiliary contactorsRated operation current Ie at AC1: 10 ANo. of NO contacts: 0No. of aux NO contacts: 1Catalogue Group: Accessories CECAux.contactor TOWAR Rated operation current Ie at AC1: 10 A Rated control circuit voltage Uc (DC): 220 V No. of NO contacts: 0 No. of NC contacts: 0 No. of aux NO contacts: 1 No. of aux NC contacts: 3 Function: Auxiliary contactors Catalogue Group: Accessories CEC
