Miniature contactors are compact, electrically controlled switches used to control and protect electric motors and other electrical loads. They are specifically designed for applications requiring smaller size and lower power consumption compared to larger contactors.Auxiliary contactors, also known as auxiliary contact blocks, are typically used in conjunction with miniature contactors to provide additional control and signaling functions within a circuit.

004642340

Image of CAEM4.22-24V-50/60Hz

CAEM4.22-24V-50/60Hz Aux.contactor

ETI Code:: 004642340
Number of poles:: 4
Rated control circuit voltage Uc (AC):: 24 V
Rated Frequency:: 50/60 Hz
No. of aux NO contacts:: 2
No. of aux NC contacts:: 2
Function:: Auxiliary contactors
Catalogue Group:: Accessories CEC

Product

Net weight of the product: 0.28 kg
Stock unit of measure: pcs

Transport Packaging

Transport packaging quantity: 1 pcs
EAN code for a transport packaging: 7890355109397
Transport packaging weight: 0.32 kg
Transport Packaging Dimensions Height: 90 mm
Transport Packaging Dimensions Width: 52 mm
Transport Packaging Dimensions Depth: 89 mm
Transport packaging volume: 0.417 dm³
Pallet quantity: 2,857 pcs
Customs tariff: 85364900

Rated operation current Ie, 400 V: 20 A
Voltage type for actuating: AC
Number of auxiliary contacts as normally open contact: 2
Number of auxiliary contacts as normally closed contact: 2
Rated control supply voltage AC 60 Hz(Min): 24 V
Rated control supply voltage AC 50 Hz(Min): 24 V
Rated control supply voltage AC 60 Hz(Max): 24 V
Rated control supply voltage AC 50 Hz(Max): 24 V

ETIM Classification – Version 9.0
