002463507
R 25-10-24V Modular contactor
- ETI Code:
- 002463507
- Rated operational current Ie at AC1:
- 25 A
- Type description:
- AC
- Rated operational current Ie AC-1/AC-7:
- 25 A
- Rated operational voltage (AC):
- 440 V
- Rated control circuit voltage Uc (AC):
- 24 V
- Current type:
- AC
- Rated frequency:
- 50/60 Hz
- No. of NO contacts:
- 1
- Function:
- Modular contactor
- Catalogue group:
- R
5 Documents
22 Logistics
Product
- EAN code for a single product
- 5902047612893
- Net weight of the product
- 0.13 kg
- Net width
- 17.5 mm
- Net height
- 88.6 mm
- Net depth
- 65 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 12 pcs
- EAN code for a basic packaging
- 3838895577942
- Basic packaging weight
- 1.56 kg
- Basic Packaging Dimensions Height
- 216 mm
- Basic Packaging Dimensions Width
- 90 mm
- Basic Packaging Dimensions Depth
- 73 mm
- Basic packaging volume
- 1.419 dm³
Transport Packaging
- Transport packaging quantity
- 120 pcs
- EAN code for a transport packaging
- 3838895577959
- Transport packaging weight
- 15.85 kg
- Transport Packaging Dimensions Height
- 190 mm
- Transport Packaging Dimensions Width
- 225 mm
- Transport Packaging Dimensions Depth
- 385 mm
- Transport packaging volume
- 16.459 dm³
- Pallet quantity
- 6,120 pcs
- Customs tariff
- 85362010
1 ETIM
- Number of contacts as normally open contact
- 1
ETIM Classification – Version 9.0
1 Diagrams
1 Software & drivers
Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
23 Tags
002463507Modular contactorR 25-10-24VETICONModular contactorsType-R1p, 1-module25 A25 AInternationalContactors ETICONModular Contactors for installation into distribution boards and accesoriesModular Contactors for instalation into distribution boardsNo. of NC contacts: 0Rated operational voltage (AC): 440 VRated operational current Ie AC-1/AC-7: 25 ARated control circuit voltage Uc (AC): 24 VCurrent type: ACFunction: Modular contactorNo. of NO contacts: 1Catalogue Group: RRated Frequency: 50 Hz/60 HzModular contactor Rated operational current Ie AC-1/AC-7: 25 A Rated control circuit voltage Uc (AC): 24 V Current type: AC No. of NO contacts: 1 No. of NC contacts: 0 Function: Modular contactor Catalogue Group: R
