Fuse link CH10x85SU gPV 15A/1500V DC 002625219
Specifications
- ETI Code:
- 002625219
- Description:
- CH10x85SU gPV 15A/1500V DC
- Class name:
- Fuse link
- Type:
- CH-SU
- Size:
- 10x85
- Rated current (A):
- 15
- Rated DC voltage (V):
- 1500
- Characteristics:
- gPV
- L/R (ms):
- 2
- Breaking capacity DC (kA):
- 50
- Application:
- For protection of photovoltaic modules
- Power dissipation (0,7x In) (W):
- 1,5
- Power dissipation (W):
- 3,6
- Operating joule integral (A2s):
- 307,4
- Prearcing joule integral (A2s):
- 28,2
- Standards:
- IEC 60269-6
Documents
Logistic Data
Product
- EAN code for a single product
- 3838895911005
- Net weight of the product
- 0.018 kg
- Customs tariff
- 85351000
- logis_net_width
- 10 mm
- logis_net_height
- 107 mm
- logis_net_depth
- 11 mm
Basic packaging
- Basic packaging quantity
- 10
- EAN code for a basic packaging
- 3838895859598
- Basic packaging weight
- 0.195 kg
Transport packaging
- Transport packaging quantity
- 160
- EAN code for a transport packaging
- 3838895859604
- Transport packaging weight
- 3.2 kg
- Pallet quantity
- 27200
