Fuse link VVA3 7,2kV/40A 004221113

Specifications

ETI Code:
004221113
Description:
VVA3 7,2kV/40A
Class name:
Fuse link
Rated minimum breaking current (A):
140
Cold resistance (mΩ):
13
Rated current (A):
40
Type:
NEW VVA without striker
Size:
192
Characteristics:
Other
Rated AC voltage (V):
7200
Indicator:
Without
Breaking capacity AC (kA):
63
Power dissipation (W):
28.5
Application:
transformer protection, motor protection, capacitor bank protection, installation in ring main unit

Documents

Product

EAN code for a single product
3838895911777
Net weight of the product
1.2 kg
Customs tariff
85351000

Basic packaging

Basic packaging quantity
1
EAN code for a basic packaging
3838895911777
Basic packaging weight
1.2 kg
Basic packaging volume
5.14

Transport packaging

Transport packaging quantity
3
EAN code for a transport packaging
3838895911784
Transport packaging weight
4.22 kg
Transport packaging volume
15.42
Pallet quantity
180
Pallet volume
925.2
Classification
EC003507
Class name
Medium-/high voltage fuse
Application
Other
Breaking capacity
63kA
Diameter
53mm
Installation technique
Air
Length
192mm
Performance category according to IEC 60282-1
Back-up
Rated current
40A
Rated frequency
45…60Hz
Rated voltage
7,2kV
Standard
IEC
Utilization category
Other
Voltage type
AC
With striker
No
ETIM Classification – Version 7.0
