Fuse link VVA3 7,2kV/125A 004221118

Specifications

ETI Code:
004221118
Description:
VVA3 7,2kV/125A
Class name:
Fuse link
Rated minimum breaking current (A):
450
Cold resistance (mΩ):
3.9
Rated current (A):
125
Type:
NEW VVA without striker
Size:
192
Characteristics:
Other
Rated AC voltage (V):
7200
Indicator:
Without
Breaking capacity AC (kA):
63
Power dissipation (W):
101
Application:
transformer protection, motor protection, capacitor bank protection, installation in ring main unit

Documents

Product

EAN code for a single product
3838895911876
Net weight of the product
2.62 kg
Customs tariff
85351000

Basic packaging

Basic packaging quantity
1
EAN code for a basic packaging
3838895911876
Basic packaging weight
2.62 kg
Basic packaging volume
5.14

Transport packaging

Transport packaging quantity
3
EAN code for a transport packaging
3838895911883
Transport packaging weight
8.48 kg
Transport packaging volume
15.42
Pallet quantity
126
Pallet volume
647.64
Classification
EC003507
Class name
Medium-/high voltage fuse
Application
Other
Breaking capacity
63kA
Diameter
83,5mm
Installation technique
Air
Length
192mm
Performance category according to IEC 60282-1
Back-up
Rated current
125A
Rated frequency
45…60Hz
Rated voltage
7,2kV
Standard
IEC
Utilization category
Other
Voltage type
AC
With striker
No
ETIM Classification – Version 7.0
