Fuse link VVA3 7,2kV/160A 004221119

Specifications

ETI Code:
004221119
Description:
VVA3 7,2kV/160A
Class name:
Fuse link
efuse:
1
Cold resistance (mΩ):
3
Rated minimum breaking current (A):
600
Rated current (A):
160
Type:
NEW VVA without striker
Size:
192
Characteristics:
Other
Rated AC voltage (V):
7200
Indicator:
Without
Breaking capacity AC (kA):
63
Application:
transformer protection, motor protection, capacitor bank protection, installation in ring main unit
Power dissipation (W):
144

Documents

Product

EAN code for a single product
3838895911890
Net weight of the product
2.62  kg
Customs tariff
85351000
logis_net_width
87  mm
logis_net_height
192  mm
logis_net_depth
87  mm

Level 1 Packaging

EAN code for a basic packaging


Level 2 Packaging

Transport packaging quantity
3
EAN code for a transport packaging
3838895911906
Transport packaging weight
8.48  kg
Pallet quantity
126
Classification
EC003507
Class name
Medium-/high voltage fuse
Max. rated operation voltage Ue AC
7200
Construction size
192
Type of fuse status indicator
Without
Rated current
160A
Rated voltage
7,2kV
Voltage type
AC
Rated frequency
45…60Hz
Breaking capacity
63kA
Utilization category
Other
Application
Other
Length
192mm
Diameter
83,5mm
Performance category according to IEC 60282-1
Back-up
With striker
No
Standard
IEC
Installation technique
Air
ETIM Classification – Version 7.0
