Fuse link VVA3 12kV/20A 004231109

Specifications

ETI Code:
004231109
Description:
VVA3 12kV/20A
Class name:
Fuse link
Rated minimum breaking current (A):
70
Cold resistance (mΩ):
44
Rated current (A):
20
Type:
NEW VVA without striker
Size:
292
Characteristics:
Other
Rated AC voltage (V):
12000
Indicator:
Without
Breaking capacity AC (kA):
63
Power dissipation (W):
21
Application:
transformer protection, motor protection, capacitor bank protection, installation in ring main unit

Documents

Product

EAN code for a single product
3838895912071
Net weight of the product
1.7 kg
Customs tariff
85351000

Basic packaging

Basic packaging quantity
1
EAN code for a basic packaging
3838895912071
Basic packaging weight
1.7 kg
Basic packaging volume
5.14

Transport packaging

Transport packaging quantity
3
EAN code for a transport packaging
3838895912088
Transport packaging weight
5.72 kg
Transport packaging volume
15.42
Pallet quantity
144
Pallet volume
740.16
Classification
EC003507
Class name
Medium-/high voltage fuse
Application
Other
Breaking capacity
63kA
Diameter
53mm
Installation technique
Air
Length
292mm
Performance category according to IEC 60282-1
Back-up
Rated current
20A
Rated frequency
45…60Hz
Rated voltage
12kV
Standard
IEC
Utilization category
Other
Voltage type
AC
With striker
No
