Fuse link VVA3 12kV/50A 004231114

Specifications

ETI Code:
004231114
Description:
VVA3 12kV/50A
Class name:
Fuse link
efuse:
1
Cold resistance (mΩ):
16.5
Rated minimum breaking current (A):
175
Rated current (A):
50
Type:
NEW VVA without striker
Size:
292
Characteristics:
Other
Rated AC voltage (V):
12000
Indicator:
Without
Breaking capacity AC (kA):
63
Power dissipation (W):
58
Application:
transformer protection, motor protection, capacitor bank protection, installation in ring main unit

Documents

Product

EAN code for a single product
3838895912170
Net weight of the product
2.8  kg
Customs tariff
85351000
logis_net_width
72  mm
logis_net_height
292  mm
logis_net_depth
72  mm

Level 1 Packaging

EAN code for a basic packaging


Level 2 Packaging

Transport packaging quantity
3
EAN code for a transport packaging
3838895912187
Transport packaging weight
9.02  kg
Pallet quantity
90
Classification
EC003507
Class name
Medium-/high voltage fuse
Type of fuse status indicator
Without
Max. rated operation voltage Ue AC
12000
Construction size
292
Rated current
50A
Rated voltage
12kV
Voltage type
AC
Rated frequency
45…60Hz
Breaking capacity
63kA
Utilization category
Other
Application
Other
Length
292mm
Diameter
68mm
Performance category according to IEC 60282-1
Back-up
Standard
IEC
Installation technique
Air
ETIM Classification – Version 7.0
