Fuse link DI UQ gR 16A/500V 004321005

Specifications

ETI Code:
004321005
Description:
DI UQ gR 16A/500V
Class name:
Fuse link
Type:
D
Size:
DI
Rated current (A):
16
Rated AC voltage (V):
500
Rated DC voltage (V):
315
Characteristics:
gR
Breaking capacity AC (kA):
50
Breaking capacity DC (kA):
8
Application:
For protection of semiconductor devices
Dimensions:
E16
Indicator:
Top fuse status indicator
Power dissipation (W):
6,3
Operating joule integral (A2s):
60
Standards:
IEC 60269-4

Documents

Product

EAN code for a single product
3838895292494
Net weight of the product
0.135 kg
Customs tariff
85361050

Basic packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895292494
Basic packaging weight
0.135 kg
Basic packaging volume
0.1

Transport packaging

Transport packaging quantity
500
EAN code for a transport packaging
3838895292500
Transport packaging weight
7.5 kg
Transport packaging volume
6.102
Pallet quantity
60000
Pallet volume
732.24
Classification
EC000099
Class name
D-system fuse link
Colour code
Grey
Construction size
DI
Nominal rated current
16A
Nominal rated voltage
500V
Release characteristic
Super fast (FF)
Utilization category
gR (general purpose semiconductor protection)
ETIM Classification – Version 7.0

Images & Diagrams

004321005Fuse link, DI UQ gR 16A/500VUltra QuickSystem DgR CharacteristicgR CharacteristicD ID IFuse links for semi conductor protection ULTRA QUICKFuse links ULTRA QUICKDI UQ GR 16A/500Tripping characteristic Super fast (FF)Rated current 16AType DRated voltage 500VSize DIProduct group Semiconductor ProtectionCharacteristics gRRated AC voltage 500VRated DC voltage 315VDimensions E16Indicator Top fuse status indicatorBreaking capacity AC 50kABreaking capacity DC 8kAPower dissipation 6,3WCatalogue Group Semiconductor ProtectionStandards IEC 60269-4Operating joule integral 60A2sApplication For protection of semiconductor devicesFuse link DI D DI 16A 500V 315V gR
