Fuse link DII UQ gR 4A/500V 004322002
Specifications
- ETI Code:
- 004322002
- Description:
- DII UQ gR 4A/500V
- Class name:
- Fuse link
- efuse:
- 1
- Product group:
- Semiconductor Protection
- Type:
- D
- Size:
- DII
- Rated current (A):
- 4
- Rated AC voltage (V):
- 500
- Rated DC voltage (V):
- 315
- Characteristics:
- gR
- Breaking capacity AC (kA):
- 50
- Breaking capacity DC (kA):
- 8
- Application:
- For protection of semiconductor devices
- Indicator:
- Top fuse status indicator
- Power dissipation (W):
- 2,5
- Operating joule integral (A2s):
- 11
- Standards:
- IEC 60269-4
Documents
Logistic Data
Product
- EAN code for a single product
- 3838895739425
- Net weight of the product
- 24 g
- Customs tariff
- 85361010
- logis_net_width
- 22 mm
- logis_net_height
- 50 mm
- logis_net_depth
- 22 mm
Basic packaging
- Basic packaging quantity
- 5
- EAN code for a basic packaging
- 3838895012184
- Basic packaging weight
- 0.13 kg
Transport packaging
- Transport packaging quantity
- 500
- EAN code for a transport packaging
- 3838895166092
- Transport packaging weight
- 13.5 kg
- Pallet quantity
- 26000
Intermediate packaging
- qty
- 1 pcs
- Weight
- 24 g
- Height (mm)
- 50
- Depth (mm)
- 22
- volume
- 0.32 dm3
ETIM Clasification
- Classification
- EC000099
- Class name
- D-system fuse link
- Construction size
- DII
- Rated current
- 4A
- Rated voltage
- 315V
- Colour code
- Brown
- Utilization category
- Other
- Release characteristic
- Super fast (FF)
Characteristic
