Fuse link DII UQ gR 6A/500V 004322003
Specifications
- ETI Code:
- 004322003
- Description:
- DII UQ gR 6A/500V
- Class name:
- Fuse link
- efuse:
- 1
- Product group:
- Semiconductor Protection
- Type:
- D
- Size:
- DII
- Rated current (A):
- 6
- Rated AC voltage (V):
- 500
- Rated DC voltage (V):
- 315
- Characteristics:
- gR
- Breaking capacity AC (kA):
- 50
- Breaking capacity DC (kA):
- 8
- Application:
- For protection of semiconductor devices
- Indicator:
- Top fuse status indicator
- Power dissipation (W):
- 3,2
- Operating joule integral (A2s):
- 18
- Standards:
- IEC 60269-4
Documents
Logistic Data
Product
- EAN code for a single product
- 3838400052032
- Net weight of the product
- 25 g
- Customs tariff
- 85361010
- logis_net_width
- 22 mm
- logis_net_height
- 50 mm
- logis_net_depth
- 22 mm
Basic packaging
- Basic packaging quantity
- 5
- EAN code for a basic packaging
- 3838895012191
- Basic packaging weight
- 0.134 kg
Transport packaging
- Transport packaging quantity
- 500
- EAN code for a transport packaging
- 3838895166108
- Transport packaging weight
- 13.85 kg
- Pallet quantity
- 26000
Intermediate packaging
- qty
- 1 pcs
- Weight
- 25 g
- Height (mm)
- 50
- Depth (mm)
- 22
- volume
- 0.028 dm3
ETIM Clasification
- Classification
- EC000099
- Class name
- D-system fuse link
- Construction size
- DII
- Rated current
- 6A
- Rated voltage
- 315V
- Colour code
- Green
- Utilization category
- Other
- Release characteristic
- Super fast (FF)
Characteristic
Images & Diagrams
Software & drivers
Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
DII UQ gR 6A/500V
