Fuse link DII UQ gR 25A/500V 004322007

Specifications

ETI Code:
004322007
Description:
DII UQ gR 25A/500V
Class name:
Fuse link
efuse:
1
Product group:
Semiconductor Protection
Type:
D
Size:
DII
Rated current (A):
25
Rated AC voltage (V):
500
Rated DC voltage (V):
315
Characteristics:
gR
Breaking capacity AC (kA):
50
Breaking capacity DC (kA):
8
Application:
For protection of semiconductor devices
Dimensions:
E27
Indicator:
Top fuse status indicator
Power dissipation (W):
9
Operating joule integral (A2s):
205
Standards:
IEC 60269-4

Documents

Product

EAN code for a single product
3838400052100
Net weight of the product
28  g
Customs tariff
85361050
logis_net_width
22  mm
logis_net_height
50  mm
logis_net_depth
22  mm

Level 1 Packaging

Basic packaging quantity
5
EAN code for a basic packaging
3838895012238
Basic packaging weight
0.158  kg

Level 2 Packaging

Transport packaging quantity
500
EAN code for a transport packaging
3838895166146
Transport packaging weight
16.3  kg
Pallet quantity
26000
Classification
EC000099
Class name
D-system fuse link
Rated voltage DC
315
Breaking capacity
50
Application
For protection of semiconductor devices
Type of fuse status indicator
Top fuse status indicator
Max. rated operation voltage Ue AC
500
Construction size
DII
Rated current
25A
Rated voltage
500V
Colour code
Yellow
Utilization category
Other
Release characteristic
Super fast (FF)
ETIM Classification – Version 7.0
