Fuse link DII UQ gR 30A/500V 004322008

Specifications

ETI Code:
004322008
Description:
DII UQ gR 30A/500V
Class name:
Fuse link
Type:
D
Size:
DII
Rated current (A):
30
Rated AC voltage (V):
500
Rated DC voltage (V):
315
Characteristics:
gR
Breaking capacity AC (kA):
50
Breaking capacity DC (kA):
8
Application:
For protection of semiconductor devices
Dimensions:
E27
Indicator:
Top fuse status indicator
Power dissipation (W):
10
Operating joule integral (A2s):
310
Standards:
IEC 60269-4

Documents

Product

EAN code for a single product
3838895028024
Net weight of the product
0.158 kg
Customs tariff
85361050

Basic packaging

Basic packaging quantity
5
EAN code for a basic packaging
3838895028024
Basic packaging weight
0.158 kg
Basic packaging volume
0.138

Transport packaging

Transport packaging quantity
500
EAN code for a transport packaging
3838895166153
Transport packaging weight
16.3 kg
Transport packaging volume
17.4
Pallet quantity
26000
Pallet volume
904.8
Classification
EC000099
Class name
D-system fuse link
Colour code
Black
Construction size
DII
Rated current
30A
Rated voltage
500V
Release characteristic
Super fast (FF)
Utilization category
gR (general purpose semiconductor protection)
ETIM Classification – Version 7.0

Images & Diagrams

004322008Fuse link, DII UQ gR 30A/500VUltra QuickSystem DgR CharacteristicgR CharacteristicD IID IIFuse links for semi conductor protection ULTRA QUICKFuse links ULTRA QUICKDII UQ GR 30A/50Tripping characteristic Super fast (FF)Rated current 30AType DRated voltage 500VSize DIIProduct group Semiconductor ProtectionCharacteristics gRRated AC voltage 500VRated DC voltage 315VDimensions E27Indicator Top fuse status indicatorBreaking capacity AC 50kABreaking capacity DC 8kAPower dissipation 10WCatalogue Group Semiconductor ProtectionStandards IEC 60269-4Operating joule integral 310A2sApplication For protection of semiconductor devicesFuse link DII D DII 30A 500V 315V gR
