Fuse link DIII UQ gR 50A/500V 004323002

Specifications

ETI Code:
004323002
Description:
DIII UQ gR 50A/500V
Class name:
Fuse link
Type:
D
Size:
DIII
Rated current (A):
50
Rated AC voltage (V):
500
Rated DC voltage (V):
315
Characteristics:
gR
Breaking capacity AC (kA):
50
Breaking capacity DC (kA):
8
Application:
For protection of semiconductor devices
Dimensions:
E33
Indicator:
Top fuse status indicator
Power dissipation (W):
19
Operating joule integral (A2s):
1.250
Standards:
IEC 60269-4

Documents

Product

EAN code for a single product
3838895012252
Net weight of the product
0.267 kg
Customs tariff
85361050

Basic packaging

Basic packaging quantity
5
EAN code for a basic packaging
3838895012252
Basic packaging weight
0.267 kg
Basic packaging volume
0.203

Transport packaging

Transport packaging quantity
250
EAN code for a transport packaging
3838895710868
Transport packaging weight
13 kg
Transport packaging volume
17.4
Pallet quantity
13000
Pallet volume
904.8
Classification
EC000099
Class name
D-system fuse link
Colour code
White
Construction size
DIII
Nominal rated current
50A
Nominal rated voltage
500V
Release characteristic
Super fast (FF)
Utilization category
gR (general purpose semiconductor protection)
ETIM Classification – Version 7.0

Images & Diagrams

004323002Fuse link, DIII UQ gR 50A/500VUltra QuickSystem DgR CharacteristicgR CharacteristicD IIID IIIFuse links for semi conductor protection ULTRA QUICKFuse links ULTRA QUICKDIII UQ GR 50A/5Tripping characteristic Super fast (FF)Rated current 50AType DRated voltage 500VSize DIIIProduct group Semiconductor ProtectionCharacteristics gRRated AC voltage 500VRated DC voltage 315VDimensions E33Indicator Top fuse status indicatorBreaking capacity AC 50kABreaking capacity DC 8kAPower dissipation 19WCatalogue Group Semiconductor ProtectionStandards IEC 60269-4Operating joule integral 1.250A2sApplication For protection of semiconductor devicesFuse link DIII D DIII 50A 500V 315V gR
