Fuse link DIII UQ gR 63A/500V 004323003

Specifications

ETI Code:
004323003
Description:
DIII UQ gR 63A/500V
Class name:
Fuse link
Type:
D
Size:
DIII
Rated current (A):
63
Rated AC voltage (V):
500
Rated DC voltage (V):
315
Characteristics:
gR
Breaking capacity AC (kA):
50
Breaking capacity DC (kA):
8
Application:
For protection of semiconductor devices
Dimensions:
E33
Indicator:
Top fuse status indicator
Power dissipation (W):
23
Operating joule integral (A2s):
1.890
Standards:
IEC 60269-4

Documents

Product

EAN code for a single product
3838895012269
Net weight of the product
0.27 kg
Customs tariff
85361050

Basic packaging

Basic packaging quantity
5
EAN code for a basic packaging
3838895012269
Basic packaging weight
0.27 kg
Basic packaging volume
0.203

Transport packaging

Transport packaging quantity
250
EAN code for a transport packaging
3838895710875
Transport packaging weight
13.6 kg
Transport packaging volume
17.4
Pallet quantity
13000
Pallet volume
904.8
Classification
EC000099
Class name
D-system fuse link
Colour code
Copper
Construction size
DIII
Rated current
63A
Rated voltage
500V
Release characteristic
Super fast (FF)
Utilization category
gR (general purpose semiconductor protection)
ETIM Classification – Version 7.0

Images & Diagrams

004323003Fuse link, DIII UQ gR 63A/500VUltra QuickSystem DgR CharacteristicgR CharacteristicD IIID IIIFuse links for semi conductor protection ULTRA QUICKFuse links ULTRA QUICKDIII UQ GR 63A/5Tripping characteristic Super fast (FF)Rated current 63AType DRated voltage 500VSize DIIIProduct group Semiconductor ProtectionCharacteristics gRRated AC voltage 500VRated DC voltage 315VDimensions E33Indicator Top fuse status indicatorBreaking capacity AC 50kABreaking capacity DC 8kAPower dissipation 23WCatalogue Group Semiconductor ProtectionStandards IEC 60269-4Operating joule integral 1.890A2sApplication For protection of semiconductor devicesFuse link DIII D DIII 63A 500V 315V gR
