VVT-D3 (striker type 80N THERMO)

VVT-D3 7,2kV/2A

Class name: Fuse link
Fuse type: NEW VVT-D 80N Thermo striker
Rated AC voltage: 7,200 V
Size: 192
Rated current: 2 A
Indicator: Temperature limiter, 80N striker force
Breaking capacity AC: 63 kA
Rated minimum breaking current: 12 A
Cold resistance: 580 mΩ
Power dissipation: 4 W

VVT-D3 7,2kV/4A

Class name: Fuse link
Fuse type: NEW VVT-D 80N Thermo striker
Rated AC voltage: 7,200 V
Size: 192
Rated current: 4 A
Indicator: Temperature limiter, 80N striker force
Breaking capacity AC: 63 kA
Rated minimum breaking current: 20 A
Cold resistance: 370 mΩ
Power dissipation: 9 W

VVT-D3 7,2kV/6A

Class name: Fuse link
Fuse type: NEW VVT-D 80N Thermo striker
Rated AC voltage: 7,200 V
Size: 192
Rated current: 6 A
Indicator: Temperature limiter, 80N striker force
Breaking capacity AC: 63 kA
Rated minimum breaking current: 25 A
Cold resistance: 250 mΩ
Power dissipation: 10 W

VVT-D3 7,2kV/6,3A

Class name: Fuse link
Fuse type: NEW VVT-D 80N Thermo striker
Rated AC voltage: 7,200 V
Size: 192
Rated current: 6.3 A
Indicator: Temperature limiter, 80N striker force
Breaking capacity AC: 63 kA
Rated minimum breaking current: 25 A
Cold resistance: 250 mΩ
Power dissipation: 10 W

VVT-D3 7,2kV/10A

Class name: Fuse link
Fuse type: NEW VVT-D 80N Thermo striker
Rated AC voltage: 7,200 V
Size: 192
Rated current: 10 A
Indicator: Temperature limiter, 80N striker force
Breaking capacity AC: 63 kA
Rated minimum breaking current: 43 A
Cold resistance: 75 mΩ
Power dissipation: 9 W

VVT-D3 7,2kV/16A

Class name: Fuse link
Fuse type: NEW VVT-D 80N Thermo striker
Rated AC voltage: 7,200 V
Size: 192
Rated current: 16 A
Indicator: Temperature limiter, 80N striker force
Breaking capacity AC: 63 kA
Rated minimum breaking current: 56 A
Cold resistance: 44 mΩ
Power dissipation: 14 W

VVT-D3 7,2kV/20A

Class name: Fuse link
Fuse type: NEW VVT-D 80N Thermo striker
Rated AC voltage: 7,200 V
Size: 192
Rated current: 20 A
Indicator: Temperature limiter, 80N striker force
Breaking capacity AC: 63 kA
Rated minimum breaking current: 70 A
Cold resistance: 27 mΩ
Power dissipation: 125 W

VVT-D3 7,2kV/25A

Class name: Fuse link
Fuse type: NEW VVT-D 80N Thermo striker
Rated AC voltage: 7,200 V
Size: 192
Rated current: 25 A
Indicator: Temperature limiter, 80N striker force
Breaking capacity AC: 63 kA
Rated minimum breaking current: 87 A
Cold resistance: 21 mΩ
Power dissipation: 16 W

VVT-D3 7,2kV/31,5A

Class name: Fuse link
Fuse type: NEW VVT-D 80N Thermo striker
Rated AC voltage: 7,200 V
Size: 192
Rated current: 31.5 A
Indicator: Temperature limiter, 80N striker force
Breaking capacity AC: 63 kA
Rated minimum breaking current: 110 A
Cold resistance: 18.5 mΩ
Power dissipation: 235 W

VVT-D3 7,2kV/32A

Class name: Fuse link
Fuse type: NEW VVT-D 80N Thermo striker
Rated AC voltage: 7,200 V
Size: 192
Rated current: 32 A
Indicator: Temperature limiter, 80N striker force
Breaking capacity AC: 63 kA
Rated minimum breaking current: 110 A
Cold resistance: 18.5 mΩ
Power dissipation: 25 W

VVT-D3 7,2kV/40A

Class name: Fuse link
Fuse type: NEW VVT-D 80N Thermo striker
Rated AC voltage: 7,200 V
Size: 192
Rated current: 40 A
Indicator: Temperature limiter, 80N striker force
Breaking capacity AC: 63 kA
Rated minimum breaking current: 140 A
Cold resistance: 13.7 mΩ
Power dissipation: 285 W

VVT-D3 7,2kV/50A

Class name: Fuse link
Fuse type: NEW VVT-D 80N Thermo striker
Rated AC voltage: 7,200 V
Size: 192
Rated current: 50 A
Indicator: Temperature limiter, 80N striker force
Breaking capacity AC: 63 kA
Rated minimum breaking current: 175 A
Cold resistance: 10.5 mΩ
Power dissipation: 355 W

VVT-D3 7,2kV/63A

Class name: Fuse link
Fuse type: NEW VVT-D 80N Thermo striker
Rated AC voltage: 7,200 V
Size: 192
Rated current: 63 A
Indicator: Temperature limiter, 80N striker force
Breaking capacity AC: 63 kA
Rated minimum breaking current: 220 A
Cold resistance: 7.5 mΩ
Power dissipation: 425 W

VVT-D3 7,2kV/80A

Class name: Fuse link
Fuse type: NEW VVT-D 80N Thermo striker
Rated AC voltage: 7,200 V
Size: 192
Rated current: 80 A
Indicator: Temperature limiter, 80N striker force
Breaking capacity AC: 63 kA
Rated minimum breaking current: 280 A
Cold resistance: 5.9 mΩ
Power dissipation: 59 W

VVT-D3 7,2kV/100A

Class name: Fuse link
Fuse type: NEW VVT-D 80N Thermo striker
Rated AC voltage: 7,200 V
Size: 192
Rated current: 100 A
Indicator: Temperature limiter, 80N striker force
Breaking capacity AC: 63 kA
Rated minimum breaking current: 360 A
Cold resistance: 4.8 mΩ
Power dissipation: 73 W

VVT-D3 7,2kV/125A

Class name: Fuse link
Fuse type: NEW VVT-D 80N Thermo striker
Rated AC voltage: 7,200 V
Size: 192
Rated current: 125 A
Indicator: Temperature limiter, 80N striker force
Breaking capacity AC: 63 kA
Rated minimum breaking current: 450 A
Cold resistance: 3.9 mΩ
Power dissipation: 101 W

VVT-D3 7,2kV/160A

Class name: Fuse link
Fuse type: NEW VVT-D 80N Thermo striker
Rated AC voltage: 7,200 V
Size: 192
Rated current: 160 A
Indicator: Temperature limiter, 80N striker force
Breaking capacity AC: 63 kA
Rated minimum breaking current: 600 A
Cold resistance: 3 mΩ
Power dissipation: 144 W

VVT-D3 7,2kV/2A 292

Class name: Fuse link
Fuse type: NEW VVT-D 80N Thermo striker
Rated AC voltage: 7,200 V
Size: 292
Rated current: 2 A
Indicator: Temperature limiter, 80N striker force
Breaking capacity AC: 63 kA
Rated minimum breaking current: 12 A
Cold resistance: 580 mΩ
Power dissipation: 4 W

VVT-D3 7,2kV/4A 292

Class name: Fuse link
Fuse type: NEW VVT-D 80N Thermo striker
Rated AC voltage: 7,200 V
Size: 292
Rated current: 4 A
Indicator: Temperature limiter, 80N striker force
Breaking capacity AC: 63 kA
Rated minimum breaking current: 20 A
Cold resistance: 370 mΩ
Power dissipation: 9 W

VVT-D3 7,2kV/6A 292

Class name: Fuse link
Fuse type: NEW VVT-D 80N Thermo striker
Rated AC voltage: 7,200 V
Size: 292
Rated current: 6 A
Indicator: Temperature limiter, 80N striker force
Breaking capacity AC: 63 kA
Rated minimum breaking current: 25 A
Cold resistance: 250 mΩ
Power dissipation: 10 W
