002412001
ZE 230V Bell / Buzzer
- ETI Code:
- 002412001
- Rated DC voltage:
- 24 V
- Standards:
- IEC/EN 60947-1, IEC/EN 60947-3
- Max input cross-section:
- 6 mm²
- Utilization category:
- AC-22A
- Rated Frequency:
- 50/60 Hz
- Application:
- IEC/EN 60947-1, IEC/EN 60947-3
- IP rating:
- IP20
- Catalogue Group:
- Bell/Buzzer/Bell transformer
- Catalogue Subgroup:
- Bell/Buzzer
- Function:
- Bell/Buzzer
5 Documents
16 Logistics
Product
- Net depth
- 63.2 mm
- Net weight of the product
- 0.076 kg
- Net width
- 17.6 mm
- Net height
- 84.5 mm
- Stock unit of measure
- pcs
- EAN code for a single product
- 3838895826668
Basic Packaging
- EAN code for a basic packaging
- 3838895299325
- Basic packaging weight
- 0.97 kg
- Basic packaging volume
- 1.47 dm³
- Basic packaging quantity
- 12 pcs
Transport Packaging
- Transport packaging weight
- 9.08 kg
- Transport packaging volume
- 17.4 dm³
- Transport packaging quantity
- 108 pcs
- Customs tariff
- 85318040
- EAN code for a transport packaging
- 3838895299332
- Pallet quantity
- 5,616 pcs
7 ETIM
- Housing colour
- Grey
- Degree of protection (IP)
- IP20
- Nominal voltage(Max)
- 230 V
- Nominal voltage(Min)
- 230 V
- Housing material
- Plastic
- Loudness
- 75 dB
- Width in number of modular spacings
- 1
ETIM Classification – Version 9.0
1 Diagrams
1 Software & drivers
Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
