RCE01 24-48 V/AC RC surge supressor
- ETI Code:
- 004641701
- To use with:
- miniature and auxiliary contactor CE
- Rated AC voltage:
- 24/48 V
- Catalogue Group:
- Accessories CE, CAE, CE17
- Function:
- Surge suppressor
5 Documents
14 Logistics
Product
- Net weight of the product
- 0.14 kg
- Net width
- 52.8 mm
- Net height
- 51.5 mm
- Net depth
- 22.8 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 1 pcs
- EAN code for a transport packaging
- 7890355110546
- Transport packaging weight
- 0.011 kg
- Transport Packaging Dimensions Height
- 33.5 mm
- Transport Packaging Dimensions Width
- 13.5 mm
- Transport Packaging Dimensions Depth
- 56 mm
- Transport packaging volume
- 0.025 dm³
- Pallet quantity
- 5,714 pcs
- Customs tariff
- 85363030
3 ETIM
- Voltage type (operating voltage)
- AC
- Function
- RC-element
- Operating voltage AC 50 Hz(Min)
- 24 V
