PH1 D3-W1 Pedestal

ETI Code:: 001336908
Function:: Plinths
To use with:: SOLID GSX system
Color:: RAL 9005
Installation:: Plinths for enclosures
Catalogue group:: Plinths
Product group accessories:: Plinths for 300mm deep HXS enclosures
Function accessories:: Plinth 100 mm height and RAL9005 for HXS300 enclosures with width 1 (300)
Height:: 100 mm
Width:: 300 mm
Depth:: 300 mm

Product

Net weight of the product: 2.472 kg
Net width: 305 mm
Net height: 105 mm
Net depth: 88 mm
Stock unit of measure: pcs

Transport Packaging

Transport packaging quantity: 1 pcs
EAN code for a transport packaging: 5902047614231
Transport packaging weight: 2.514 kg
Transport Packaging Dimensions Height: 110 mm
Transport Packaging Dimensions Width: 360 mm
Transport Packaging Dimensions Depth: 98 mm
Transport packaging volume: 3.881 dm³
Customs tariff: 85381000

Width: 300 mm
Suitable for enclosure building depth: 300 mm
Model: Base complete
Impact strength: IK10
Suitable for cable patch: ✓
RAL-number (similar): 9,005
Suitable for enclosure building width: 300 mm
Depth: 300 mm
Colour: Black
Material: Steel
Height: 100 mm
