004325002
DV UQ gR 160A/500V Fuse link
- ETI Code:
- 004325002
- Product group:
- Semiconductor Protection
- Catalogue Group:
- Semiconductor Protection
- Operating joule integral (A2s):
- 24,000
- Application:
- For protection of semiconductor devices
- Type description:
- D
- Size:
- DV
- Time-Current Characteristic:
- gR
- Rated AC voltage:
- 500 V
- Rated DC voltage:
- 315 V
- Rated current:
- 160 A
- Power dissipation:
- 71 W
- Breaking capacity AC:
- 50 kA
- Breaking capacity DC:
- 8 kA
- Fuse type:
- D
- Indicator:
- Top fuse status indicator
- Standards:
- IEC 60269-4
22 Logistics
Product
- EAN code for a single product
- 3838400052186
- Net weight of the product
- 210 g
- Net width
- 46 mm
- Net height
- 56 mm
- Net depth
- 46 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 10 pcs
- EAN code for a basic packaging
- 3838895012306
- Basic packaging weight
- 2.4 kg
- Basic Packaging Dimensions Height
- 0.068 m
- Basic Packaging Dimensions Width
- 0.115 m
- Basic Packaging Dimensions Depth
- 0.258 m
- Basic packaging volume
- 0.002 m³
Transport Packaging
- Transport packaging quantity
- 60 pcs
- EAN code for a transport packaging
- 3838895166221
- Transport packaging weight
- 14.75 kg
- Transport Packaging Dimensions Height
- 0.25 m
- Transport Packaging Dimensions Width
- 0.235 m
- Transport Packaging Dimensions Depth
- 0.295 m
- Transport packaging volume
- 0.017 m³
- Pallet quantity
- 3,120 pcs
- Customs tariff
- 85361090
6 ETIM
- Colour code
- Copper
- Release characteristic
- Super fast (FF)
- Construction size
- DV
- Rated voltage
- 315 V
- Rated current
- 160 A
- Utilization category
- Other
ETIM Classification – Version 9.0
