D0 fuse links - Products & Solutions

D01 gG 2A/400V

Class name: Fuse link
Fuse type: D0
Size: D01
Time-Current Characteristic: gG
Rated AC voltage: 400 V
Rated DC voltage: 250 V
Rated current: 2 A
Power dissipation: 2.1 W
Breaking capacity AC: 50 kA
Breaking capacity DC: 8 kA
Prearcing joule integral (A2s): 1.2
Operating joule integral (A2s): 11.9
Indicator: Top fuse status indicator
Standards: DIN EN 60269-1, DIN EN 60269-3
Application: For cable protection

D01 gG 4A/400V

Class name: Fuse link
Fuse type: D0
Size: D01
Time-Current Characteristic: gG
Rated AC voltage: 400 V
Rated DC voltage: 250 V
Rated current: 4 A
Power dissipation: 1.4 W
Breaking capacity AC: 50 kA
Breaking capacity DC: 8 kA
Prearcing joule integral (A2s): 12.5
Operating joule integral (A2s): 30.5
Indicator: Top fuse status indicator
Standards: DIN EN 60269-1, DIN EN 60269-3
Application: For cable protection

D01 gG 6A/400V

Class name: Fuse link
Fuse type: D0
Size: D01
Time-Current Characteristic: gG
Rated AC voltage: 400 V
Rated DC voltage: 250 V
Rated current: 6 A
Power dissipation: 1.8 W
Breaking capacity AC: 50 kA
Breaking capacity DC: 8 kA
Prearcing joule integral (A2s): 49.4
Operating joule integral (A2s): 71
Indicator: Top fuse status indicator
Standards: DIN EN 60269-1, DIN EN 60269-3
Application: For cable protection

D01 gG 10A/400V

Class name: Fuse link
Fuse type: D0
Size: D01
Time-Current Characteristic: gG
Rated AC voltage: 400 V
Rated DC voltage: 250 V
Rated current: 10 A
Power dissipation: 1.3 W
Breaking capacity AC: 50 kA
Breaking capacity DC: 8 kA
Prearcing joule integral (A2s): 120
Operating joule integral (A2s): 338
Indicator: Top fuse status indicator
Standards: DIN EN 60269-1, DIN EN 60269-3
Application: For cable protection

D01 gG 13A/400V

Class name: Fuse link
Fuse type: D0
Size: D01
Time-Current Characteristic: gG
Rated AC voltage: 400 V
Rated DC voltage: 250 V
Rated current: 13 A
Power dissipation: 2.2 W
Breaking capacity AC: 50 kA
Breaking capacity DC: 8 kA
Prearcing joule integral (A2s): 219
Operating joule integral (A2s): 750
Indicator: Top fuse status indicator
Standards: DIN EN 60269-1, DIN EN 60269-3
Application: For cable protection

D01 gG 16A/400V

Class name: Fuse link
Fuse type: D0
Size: D01
Time-Current Characteristic: gG
Rated AC voltage: 400 V
Rated DC voltage: 250 V
Rated current: 16 A
Power dissipation: 2 W
Breaking capacity AC: 50 kA
Breaking capacity DC: 8 kA
Prearcing joule integral (A2s): 406
Operating joule integral (A2s): 795
Indicator: Top fuse status indicator
Standards: DIN EN 60269-1, DIN EN 60269-3
Application: For cable protection

D02 gG 20A/400V

Class name: Fuse link
Fuse type: D0
Size: D02
Time-Current Characteristic: gG
Rated AC voltage: 400 V
Rated DC voltage: 250 V
Rated current: 20 A
Power dissipation: 2.7 W
Breaking capacity AC: 50 kA
Breaking capacity DC: 8 kA
Prearcing joule integral (A2s): 740
Operating joule integral (A2s): 1,800
Indicator: Top fuse status indicator
Standards: DIN EN 60269-1, DIN EN 60269-3
Application: For cable protection

D02 gG 25A/400V

Class name: Fuse link
Fuse type: D0
Size: D02
Time-Current Characteristic: gG
Rated AC voltage: 400 V
Rated DC voltage: 250 V
Rated current: 25 A
Power dissipation: 2.8 W
Breaking capacity AC: 50 kA
Breaking capacity DC: 8 kA
Prearcing joule integral (A2s): 1,210
Operating joule integral (A2s): 3,170
Indicator: Top fuse status indicator
Standards: DIN EN 60269-1, DIN EN 60269-3
Application: For cable protection

D02 gG 32A/400V

Class name: Fuse link
Fuse type: D0
Size: D02
Time-Current Characteristic: gG
Rated AC voltage: 400 V
Rated DC voltage: 250 V
Rated current: 32 A
Power dissipation: 3.5 W
Breaking capacity AC: 50 kA
Breaking capacity DC: 8 kA
Prearcing joule integral (A2s): 2,620
Operating joule integral (A2s): 4,840
Indicator: Top fuse status indicator
Standards: DIN EN 60269-1, DIN EN 60269-3
Application: For cable protection

D02 gG 35A/400V

Class name: Fuse link
Fuse type: D0
Size: D02
Time-Current Characteristic: gG
Rated AC voltage: 400 V
Rated DC voltage: 250 V
Rated current: 35 A
Power dissipation: 3.5 W
Breaking capacity AC: 50 kA
Breaking capacity DC: 8 kA
Prearcing joule integral (A2s): 3,110
Operating joule integral (A2s): 6,640
Indicator: Top fuse status indicator
Standards: DIN EN 60269-1, DIN EN 60269-3
Application: For cable protection

D02 gG 40A/400V

Class name: Fuse link
Fuse type: D0
Size: D02
Time-Current Characteristic: gG
Rated AC voltage: 400 V
Rated DC voltage: 250 V
Rated current: 40 A
Power dissipation: 4 W
Breaking capacity AC: 50 kA
Breaking capacity DC: 8 kA
Prearcing joule integral (A2s): 5,060
Operating joule integral (A2s): 9,170
Indicator: Top fuse status indicator
Standards: DIN EN 60269-1, DIN EN 60269-3
Application: For cable protection

D02 gG 50A/400V

Class name: Fuse link
Fuse type: D0
Size: D02
Time-Current Characteristic: gG
Rated AC voltage: 400 V
Rated DC voltage: 250 V
Rated current: 50 A
Power dissipation: 4.4 W
Breaking capacity AC: 50 kA
Breaking capacity DC: 8 kA
Prearcing joule integral (A2s): 6,750
Operating joule integral (A2s): 15,100
Indicator: Top fuse status indicator
Standards: DIN EN 60269-1, DIN EN 60269-3
Application: For cable protection

D02 gG 63A/400V

Class name: Fuse link
Fuse type: D0
Size: D02
Time-Current Characteristic: gG
Rated AC voltage: 400 V
Rated DC voltage: 250 V
Rated current: 63 A
Power dissipation: 5.4 W
Breaking capacity AC: 50 kA
Breaking capacity DC: 8 kA
Prearcing joule integral (A2s): 10,000
Operating joule integral (A2s): 22,900
Indicator: Top fuse status indicator
Standards: DIN EN 60269-1, DIN EN 60269-3
Application: For cable protection

D03 gG 80A/400V

Class name: Fuse link
Fuse type: D0
Size: D03
Time-Current Characteristic: gG
Rated AC voltage: 400 V
Rated DC voltage: 250 V
Rated current: 80 A
Power dissipation: 5.3 W
Breaking capacity AC: 50 kA
Breaking capacity DC: 8 kA
Prearcing joule integral (A2s): 12,960
Operating joule integral (A2s): 34,560
Indicator: Top fuse status indicator
Standards: DIN EN 60269-1, DIN EN 60269-3
Application: For cable protection

D03 gG 100A/400V

Class name: Fuse link
Fuse type: D0
Size: D03
Time-Current Characteristic: gG
Rated AC voltage: 400 V
Rated DC voltage: 250 V
Rated current: 100 A
Power dissipation: 6.4 W
Breaking capacity AC: 50 kA
Breaking capacity DC: 8 kA
Prearcing joule integral (A2s): 22,100
Operating joule integral (A2s): 60,260
Indicator: Top fuse status indicator
Standards: DIN EN 60269-1, DIN EN 60269-3
Application: For cable protection

D01 UQ gR 2A/400V

Class name: Fuse link
Fuse type: D0
Size: D01
Time-Current Characteristic: gR
Rated AC voltage: 400 V
Rated DC voltage: 250 V
Rated current: 2 A
Power dissipation: 2.3 W
Breaking capacity AC: 50 kA
Breaking capacity DC: 8 kA
Operating joule integral (A2s): 6
Indicator: Top fuse status indicator
Standards: IEC 60269-4
Application: For protection of semiconductor devices

D01 UQ gR 4A/400V

Class name: Fuse link
Fuse type: D0
Size: D01
Time-Current Characteristic: gR
Rated AC voltage: 400 V
Rated DC voltage: 250 V
Rated current: 4 A
Power dissipation: 3.1 W
Breaking capacity AC: 50 kA
Breaking capacity DC: 8 kA
Operating joule integral (A2s): 13
Indicator: Top fuse status indicator
Standards: IEC 60269-4
Application: For protection of semiconductor devices

D01 UQ gR 6A/400V

Class name: Fuse link
Fuse type: D0
Size: D01
Time-Current Characteristic: gR
Rated AC voltage: 400 V
Rated DC voltage: 250 V
Rated current: 6 A
Power dissipation: 4 W
Breaking capacity AC: 50 kA
Breaking capacity DC: 8 kA
Operating joule integral (A2s): 20
Indicator: Top fuse status indicator
Standards: IEC 60269-4
Application: For protection of semiconductor devices

D01 UQ gR 10A/400V

Class name: Fuse link
Fuse type: D0
Size: D01
Time-Current Characteristic: gR
Rated AC voltage: 400 V
Rated DC voltage: 250 V
Rated current: 10 A
Power dissipation: 4.2 W
Breaking capacity AC: 50 kA
Breaking capacity DC: 8 kA
Operating joule integral (A2s): 65
Indicator: Top fuse status indicator
Standards: IEC 60269-4
Application: For protection of semiconductor devices

D01 UQ gR 16A/400V

Class name: Fuse link
Fuse type: D0
Size: D01
Time-Current Characteristic: gR
Rated AC voltage: 400 V
Rated DC voltage: 250 V
Rated current: 16 A
Power dissipation: 5.3 W
Breaking capacity AC: 50 kA
Breaking capacity DC: 8 kA
Operating joule integral (A2s): 200
Indicator: Top fuse status indicator
Standards: IEC 60269-4
Application: For protection of semiconductor devices
