Fuseholders for cylindrical DC fuse-links are critical components in electrical systems, designed to securely house and connect cylindrical fuse-links. These devices ensure safe and reliable operation by providing a stable interface between the fuse-link and the DC circuit. They are essential for protecting electrical equipment from overcurrent conditions in applications such as photovoltaic systems, industrial DC systems, and energy storage installations.

This product is obsolete and does not have a direct substitute, please contact our technical support in order to find a suitable replacement.

002543102 Obsolete

Image of *VLC 10 DC 2p LED

*VLC 10 DC 2p LED Fuse disconnector

ETI Code:: 002543102
Product group:: LV-fuse disconnector
Catalogue Group:: LV-fuse disconnector
Number of poles:: 2
Rated current:: 25 A
Rated DC voltage:: 1000 V
Indicator:: LED

Product

Net weight of the product: 0.112 kg
Stock unit of measure: pcs

Basic Packaging

Basic packaging quantity: 6 pcs
EAN code for a basic packaging: 3838895596431
Basic packaging weight: 0.749 kg
Basic packaging volume: 1.47 dm³

Transport Packaging

Transport packaging quantity: 54 pcs
EAN code for a transport packaging: 3838895596448
Transport packaging weight: 7.101 kg
Transport packaging volume: 17.4 dm³
Pallet quantity: 2,808 pcs
Customs tariff: 85389099

With error protection: Yes
Rated permanent current Iu: 25 A
Suitable for fuses: Other
Type of control element: Cover grip
Type of electrical connection of main circuit: Frame clamp
Degree of protection (IP), front side: IP20
Number of poles: 2
Suitable for busbar mounting: Yes

ETIM Classification – Version 9.0
