002550203 Obsolete

*PCF 10 DC 2p 1000V Fuse disconnector

ETI Code:: 002550203
Product group:: LV-fuse disconnector
Catalogue Group:: LV-fuse disconnector
Number of poles:: 2
Rated current:: 25 A
Rated DC voltage:: 1000 V

Accessories

Product

Net weight of the product: 0.12 kg
Net width: 35.3 mm
Net height: 85.3 mm
Net depth: 70.86 mm
Stock unit of measure: pcs

Basic Packaging

Basic packaging quantity: 6 pcs
EAN code for a basic packaging: 3838895489597
Basic packaging weight: 0.71 kg
Basic packaging volume: 1.47 dm³

Transport Packaging

Transport packaging quantity: 54 pcs
EAN code for a transport packaging: 3838895618225
Transport packaging weight: 6.4 kg
Transport packaging volume: 48 dm³
Pallet quantity: 2,808 pcs
Customs tariff: 85389099

Rated permanent current Iu: 25 A
Suitable for fuses: Other
Type of control element: Cover grip
Type of electrical connection of main circuit: Frame clamp
Degree of protection (IP), front side: IP20
Number of poles: 2
Suitable for busbar mounting: Yes

ETIM Classification – Version 9.0

Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.

002550203 Fuse disconnector *PCF 10 DC 2p 1000V Green protect PCF PCF 10 DC PCF 10 DC PCF 10 DC Without indicator International Fuse links D, D0, C Fuse holders for CH DC fuse links Number of poles: 2 Rated DC voltage: 1000 V/1000 V Rated current: 25 A/25 A Fuse disconnector TOWAR Number of poles: 2 Rated current: 25 A/25 A Rated DC voltage: 1000 V/1000 V

Accessories 2 All Accessories

002540203

EFH 10 DC 2p

002550603
