002560207
EFH 14 DC 2p 1100V Fuse - base
- ETI Code:
- 002560207
- To use with:
- CH gPV fuse-links
- Product group:
- LV-fuse base
- Catalogue Group:
- LV-fuse disconnector
- Max Permissable Power Dissipation per Fuse Link:
- 5 W
- IP rating:
- IP20
- Type description:
- EFH
- Size:
- 14x51
- Number of poles:
- 2
- Type of Installation:
- DIN rail
- Utilization category:
- DC-20B
- Rated current:
- 50 A
- Rated DC voltage:
- 1100 V
- Standards:
- IEC60947-1, IEC60947-3, UL4248-1, UL4248-18, UL286E
- Ambient temperature:
- -5/40 °C
- Application:
- Photovoltaic Installation
22 Logistics
Product
- EAN code for a single product
- 3838400057259
- Net weight of the product
- 206 g
- Net width
- 54 mm
- Net height
- 94 mm
- Net depth
- 75.84 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 6 pcs
- EAN code for a basic packaging
- 3838895791928
- Basic packaging weight
- 1.302 kg
- Basic Packaging Dimensions Height
- 0.083 m
- Basic Packaging Dimensions Width
- 0.097 m
- Basic Packaging Dimensions Depth
- 0.327 m
- Basic packaging volume
- 0.003 m³
Transport Packaging
- Transport packaging quantity
- 48 pcs
- EAN code for a transport packaging
- 3838895791935
- Transport packaging weight
- 10.968 kg
- Transport Packaging Dimensions Height
- 0.215 m
- Transport Packaging Dimensions Width
- 0.368 m
- Transport Packaging Dimensions Depth
- 0.368 m
- Transport packaging volume
- 0.029 m³
- Pallet quantity
- 1,152 pcs
- Customs tariff
- 85389099
4 ETIM
- For fuse size
- 14x51 mm
- Mounting method
- Other
- Nominal voltage
- 1,100 V
- Number of poles
- 2
ETIM Classification – Version 9.0
