006710325
Mini fuse 6,3x32 HT 4A/500V Fuse link
- ETI Code:
- 006710325
- Product group:
- Mini fuse
- Catalogue Group:
- Mini fuse
- Type description:
- CH
- Fuse type:
- CH
- Size:
- 6,3x32
- Time-Current Characteristic:
- HT
- Rated AC voltage:
- 500 V
- Rated DC voltage:
- 500 V
- Rated current:
- 4 A
- Standards:
- IEC 60127-1, IEC 60127-2
- Application:
- Electronic devices protection
- Power dissipation:
- 0.95 W
- Breaking capacity AC:
- 1.5 kA
- Operating joule integral (A2s):
- 68
5 Documents
12 Logistics
Product
- EAN code for a single product
- 3838400170590
- Net weight of the product
- 0.01 kg
- Net width
- 6.4 mm
- Net height
- 31.8 mm
- Net depth
- 6.35 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 10 pcs
- EAN code for a transport packaging
- 8024873024262
- Transport packaging weight
- 0.1 kg
- Transport packaging volume
- 0.01 dm³
- Pallet quantity
- 80,000 pcs
- Customs tariff
- 85361010
5 ETIM
- Model
- Ceramic fuse
- Release characteristic
- Other
- Size
- 6.3x32 mm
- Rated voltage
- 500 V
- Rated current
- 4 A
ETIM Classification – Version 9.0
