CH14x51 SRF20-II/600V Fuse link

ETI Code:: 002636005
Product group:: Special purpose fuses
Product subgroup:: SRF
Catalogue Group:: Special purpose fuses
Catalogue Subgroup:: TVSS Protection Fuse - SRF
Type description:: CH
Fuse type:: CH
Size:: 14x51
Overvoltage Category:: II
Surge Rating for SRF Fuse:: 20,000 A
Rated AC voltage:: 600 V
Breaking capacity AC:: 200 kA
Application:: These fuses are intended for installation in series with TVSS devices
Operating joule integral (A2s):: 17,700
Prearcing joule integral (A2s):: 5,490
Standards:: Comply with the applicable requirements in UL 248-1 Low Voltage Fuses- Part1, General Requirements.

Product

EAN code for a single product: 3838400063168
Net weight of the product: 0.029 kg
Net width: 14.3 mm
Net height: 51 mm
Net depth: 14.3 mm
Stock unit of measure: pcs

Basic Packaging

Basic packaging quantity: 10 pcs
EAN code for a basic packaging: 3838895489399
Basic packaging weight: 0.297 kg
Basic Packaging Dimensions Height: 0.075 m
Basic Packaging Dimensions Width: 0.105 m
Basic Packaging Dimensions Depth: 0.015 m
Basic packaging volume: 0 m³

Transport Packaging

Transport packaging quantity: 200 pcs
EAN code for a transport packaging: 3838895738046
Transport packaging weight: 6.021 kg
Transport Packaging Dimensions Height: 107 mm
Transport Packaging Dimensions Width: 225 mm
Transport Packaging Dimensions Depth: 165 mm
Transport packaging volume: 3.972 dm³
Pallet quantity: 24,000 pcs
Customs tariff: 85361050

Size: 14x51 mm
Breaking capacity: 200 kA
Utilization category: Other

ETIM Classification – Version 9.0
