004110105
NH00/K 800A/80V DC Fuse link
- ETI Code:
- 004110105
- Fuse type:
- NH-K
- Size:
- NH00
- Rated current:
- 800 A
- Time-Current Characteristic:
- Other
- Indicator:
- Striker pin status indicator
- Rated DC voltage:
- 80 V
- Breaking capacity DC:
- 25 kA
- L/R:
- 20 ms
- Power dissipation:
- 39 W
- Prearcing joule integral (A2s):
- 8,500,000
- Operating joule integral (A2s):
- 9,700,000
- Standards:
- IEC 60269
- Application:
- Fuse link for DC application
5 Documents
22 Logistics
Product
- Net depth
- 59.5 mm
- Net weight of the product
- 220 g
- Net width
- 29 mm
- Net height
- 86.5 mm
- Stock unit of measure
- pcs
- EAN code for a single product
- 3838895760689
Basic Packaging
- EAN code for a basic packaging
- 3838895484721
- Basic packaging weight
- 0.691 kg
- Basic Packaging Dimensions Depth
- 0.107 m
- Basic Packaging Dimensions Height
- 0.063 m
- Basic packaging volume
- 0.001 m³
- Basic Packaging Dimensions Width
- 0.095 m
- Basic packaging quantity
- 3 pcs
Transport Packaging
- Transport packaging weight
- 12.793 kg
- Transport packaging volume
- 0.018 m³
- Transport packaging quantity
- 54 pcs
- Customs tariff
- 85361090
- Transport Packaging Dimensions Height
- 0.255 m
- Transport Packaging Dimensions Width
- 0.295 m
- Transport Packaging Dimensions Depth
- 0.235 m
- EAN code for a transport packaging
- 3838895760696
- Pallet quantity
- 2,808 pcs
8 ETIM
- Voltage type
- DC
- Fuse construction type according to IEC 60269
- NH00
- Power loss at rated current
- 39 W
- Rated switching capacity DC
- 25 kA
- Type of fuse status indicator
- Other
- Rated current
- 800 A
- Rated voltage DC
- 80
- Utilization category
- Other
ETIM Classification – Version 9.0
