004122006
PK 4 M12-M12 1p Fuse - base
- ETI Code:
- 004122006
- IP rating:
- IP00
- Type description:
- PK
- Size:
- NH4
- Number of poles:
- 1
- Rated current:
- 1250 A
- Rated AC voltage:
- 500 V
- Type of Installation:
- Base plate mounting
5 Documents
21 Logistics
Product
- Net weight of the product
- 3.223 kg
- Net width
- 102 mm
- Net height
- 310 mm
- Net depth
- 144 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 1 pcs
- EAN code for a basic packaging
- 3838895003106
- Basic packaging weight
- 3.295 kg
- Basic Packaging Dimensions Height
- 113 mm
- Basic Packaging Dimensions Width
- 333 mm
- Basic Packaging Dimensions Depth
- 169 mm
- Basic packaging volume
- 6.359 dm³
Transport Packaging
- Transport packaging quantity
- 7 pcs
- EAN code for a transport packaging
- 3838895161455
- Transport packaging weight
- 23.865 kg
- Transport Packaging Dimensions Height
- 0.215 m
- Transport Packaging Dimensions Width
- 0.37 m
- Transport Packaging Dimensions Depth
- 0.375 m
- Transport packaging volume
- 0.03 m³
- Pallet quantity
- 140 pcs
- Customs tariff
- 85389099
5 ETIM
- Mounting method
- Screw-on
- Construction size
- NH4
- Number of poles
- 1
- Connection type
- Screwed terminal
- Rated current
- 1,250 A
ETIM Classification – Version 9.0
