NH1 gG 80A/400V MET Fuse link

ETI Code:: 004113835
Fuse type:: NH
Size:: NH1
Rated current:: 80 A
Time-Current Characteristic:: gG
Indicator:: Top fuse status indicator
Rated AC voltage:: 400 V
Breaking capacity AC:: 50 kA
Power dissipation:: 5.2 W
Standards:: IEC EN 60269-1
Application:: As metering fuse with strip fuse switch disconnector and fuse switch disconnector

Accessories

Product

Net weight of the product: 350 g
Net width: 46 mm
Net height: 135.5 mm
Net depth: 61.8 mm
Stock unit of measure: pcs

Basic Packaging

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895618256
Basic packaging weight: 0.39 kg
Basic Packaging Dimensions Height: 0.139 m
Basic Packaging Dimensions Width: 0.07 m
Basic Packaging Dimensions Depth: 0.052 m
Basic packaging volume: 0.001 m³

Transport Packaging

Transport packaging quantity: 26 pcs
EAN code for a transport packaging: 3838895618263
Transport packaging weight: 10.49 kg
Transport Packaging Dimensions Height: 0.255 m
Transport Packaging Dimensions Width: 0.295 m
Transport Packaging Dimensions Depth: 0.235 m
Transport packaging volume: 0.018 m³
Pallet quantity: 1,352 pcs
Customs tariff: 85361090

Rated switching capacity AC: 50 kA
Voltage type: AC
Fuse construction type according to IEC 60269: NH1
Rated voltage AC: 400
Power loss at rated current: 5.2 W
Type of fuse status indicator: Top fuse status indicator
Rated current: 80 A
Utilization category: gG (cable protection/equipment protection)

ETIM Classification – Version 9.0
