004184493
Obsolete
*NH00 gG 40A/800V Fuse link
- ETI Code:
- 004184493
- Rated DC voltage:
- 800 V
- Fuse type:
- NH
- Size:
- NH00
- Rated current:
- 40 A
- Time-Current Characteristic:
- gG
- Indicator:
- Top fuse status indicator
- Rated AC voltage:
- 800 V
- Breaking capacity AC:
- 30 kA
- Power dissipation:
- 4 W
- Prearcing joule integral (A2s):
- 2,500
- Operating joule integral (A2s):
- 7,000
- Standards:
- IEC 60269-2
- Application:
- For cable protection on a.c. side of PV inverter
16 Logistics
Product
- EAN code for a single product
- 3838400062147
- Net weight of the product
- 190 g
- Net width
- 28 mm
- Net height
- 79 mm
- Net depth
- 56 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 3 pcs
- EAN code for a basic packaging
- 3838895819066
- Basic packaging weight
- 0.597 kg
- Basic packaging volume
- 0.45 dm³
Transport Packaging
- Transport packaging quantity
- 90 pcs
- EAN code for a transport packaging
- 3838895819073
- Transport packaging weight
- 18.09 kg
- Transport packaging volume
- 17.4 dm³
- Pallet quantity
- 4,680 pcs
- Customs tariff
- 85361050
6 ETIM
- Rated switching capacity AC
- 30 kA
- Voltage type
- AC
- Rated voltage AC
- 800 V
- Type of fuse status indicator
- Top fuse status indicator
- Rated current
- 40 A
- Utilization category
- gG (cable protection/equipment protection)
ETIM Classification – Version 9.0
