004184505
NH00 gS 20A/800V Fuse link
- ETI Code:
- 004184505
- Fuse type:
- NH
- Size:
- NH00
- Rated current:
- 20 A
- Time-Current Characteristic:
- gS
- Indicator:
- Top fuse status indicator
- Rated AC voltage:
- 800 V
- Breaking capacity AC:
- 30 kA
- Power dissipation:
- 3.2 W
- Prearcing joule integral (A2s):
- 32
- Operating joule integral (A2s):
- 1,200
- Standards:
- IEC 60269-4
- Application:
- For cable protection on a.c. side of PV inverter
22 Logistics
Product
- EAN code for a single product
- 3838895855187
- Net weight of the product
- 220 g
- Net width
- 29 mm
- Net height
- 78.9 mm
- Net depth
- 59.5 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 3 pcs
- EAN code for a basic packaging
- 3838895855194
- Basic packaging weight
- 0.683 kg
- Basic Packaging Dimensions Height
- 0.065 m
- Basic Packaging Dimensions Width
- 0.094 m
- Basic Packaging Dimensions Depth
- 0.083 m
- Basic packaging volume
- 0.001 m³
Transport Packaging
- Transport packaging quantity
- 90 pcs
- EAN code for a transport packaging
- 3838895855200
- Transport packaging weight
- 20.852 kg
- Transport Packaging Dimensions Height
- 0.255 m
- Transport Packaging Dimensions Width
- 0.295 m
- Transport Packaging Dimensions Depth
- 0.235 m
- Transport packaging volume
- 0.018 m³
- Pallet quantity
- 4,680 pcs
- Customs tariff
- 85361050
8 ETIM
- Rated switching capacity AC
- 30 kA
- Voltage type
- AC
- Fuse construction type according to IEC 60269
- NH00
- Rated voltage AC
- 800
- Power loss at rated current
- 3.2 W
- Type of fuse status indicator
- Top fuse status indicator
- Rated current
- 20 A
- Utilization category
- Other
ETIM Classification – Version 9.0
