002191123
ETIMAT 1N 1p+N C13 6kA Miniature circuit breaker
- ETI Code:
- 002191123
- Catalogue Group:
- ETIMAT 1N Miniature circuit breakers 2 poles in 1
- Application:
- IEC/EN 60898-1
- Rated current:
- 13 A
- Tripping characteristic:
- C
- Number of poles:
- 1+N
- Short circuit capacity:
- 6 kA
- Voltage type:
- AC
- Rated impulse withstand voltage Uimp:
- 4 kV
- Rated AC voltage:
- 230 V
- Rated Frequency:
- 50/60 Hz
- Rated cross section:
- 1-10 mm²
- Standards:
- IEC/EN 60898-1
- Function:
- MCB
7 Documents
22 Logistics
Product
- Net depth
- 73.97 mm
- Net weight of the product
- 0.1 kg
- Net width
- 17.9 mm
- Net height
- 88.2 mm
- Stock unit of measure
- pcs
- EAN code for a single product
- 3838895474845
Basic Packaging
- EAN code for a basic packaging
- 3838895474852
- Basic packaging weight
- 1.256 kg
- Basic Packaging Dimensions Depth
- 0.221 m
- Basic Packaging Dimensions Height
- 0.077 m
- Basic packaging volume
- 0.002 m³
- Basic Packaging Dimensions Width
- 0.09 m
- Basic packaging quantity
- 12 pcs
Transport Packaging
- Transport packaging weight
- 11.657 kg
- Transport packaging volume
- 0.017 m³
- Transport packaging quantity
- 108 pcs
- Customs tariff
- 85362010
- Transport Packaging Dimensions Height
- 0.25 m
- Transport Packaging Dimensions Width
- 0.235 m
- Transport Packaging Dimensions Depth
- 0.295 m
- EAN code for a transport packaging
- 3838895474869
- Pallet quantity
- 5,616 pcs
20 ETIM
- Built-in depth
- 68 mm
- Connectable conductor cross section solid-core(Max)
- 10 mm²
- Voltage type
- AC
- Connectable conductor cross section multi-wired(Max)
- 10 mm²
- Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
- 6 kA
- Rated impulse withstand voltage Uimp
- 4 kV
- Frequency(Min)
- 50 Hz
- Degree of protection (IP)
- IP20
- Release characteristic
- C
- Number of poles (total)
- 2
- Connectable conductor cross section solid-core(Min)
- 1 mm²
- Frequency(Max)
- 50
- Connectable conductor cross section multi-wired(Min)
- 1 mm²
- Concurrently switching neutral conductor
- Yes
- Number of protected poles
- 1
- Rated voltage
- 230 V
- Current limiting class
- 3
- Rated current
- 13 A
- Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
- 6 kA
- Width in number of modular spacings
- 1
ETIM Classification – Version 9.0
