290241107
Obsolete
*ETIMAT P10-QC 3p+N C2 Miniature circuit breaker
- ETI Code:
- 290241107
- Catalogue Group:
- ETIMAT P10 Miniature circuit breakers 10kA
- Application:
- IEC/EN 60898-1, IEC 60947-2
- Rated current:
- 2 A
- Tripping characteristic:
- C
- Number of poles:
- 3+N
- Short circuit capacity:
- 10 kA
- Voltage type:
- AC
- Rated impulse withstand voltage Uimp:
- 6 kV
- Rated AC voltage:
- 400 V
- Rated Frequency:
- 50/60 Hz
- Rated cross section:
- 1-25 mm²
- Standards:
- IEC/EN 60898-1, IEC 60947-2
- Function:
- MCB
19 Logistics
Product
- EAN code for a single product
- 3838895684688
- Net weight of the product
- 478.33 g
- Net width
- 72 mm
- Net height
- 90.1 mm
- Net depth
- 74.47 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 3 pcs
- EAN code for a basic packaging
- 3838895684695
- Basic packaging weight
- 1.464 kg
- Basic packaging volume
- 1.47 dm³
Transport Packaging
- Transport packaging quantity
- 15 pcs
- EAN code for a transport packaging
- 3838895684701
- Transport packaging weight
- 7.52 kg
- Transport Packaging Dimensions Height
- 91 mm
- Transport Packaging Dimensions Width
- 531 mm
- Transport Packaging Dimensions Depth
- 233 mm
- Transport packaging volume
- 11.259 dm³
- Pallet quantity
- 1,260 pcs
- Customs tariff
- 85362010
