004672296
Obsolete
* EB2 400/4HLCD 250A 4p APGNSC Molded Case Circuit Breaker
- ETI Code:
- 004672296
- Short circuit capacity:
- 70 kA
- Rated current:
- 250 A
- Number of poles:
- 4
- Catalogue Group:
- EB2
- Frame Size:
- 250A
5 Documents
11 Logistics
Product
- Net weight of the product
- 5.7 kg
- Net width
- 185 mm
- Net height
- 260 mm
- Net depth
- 145 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 1 pcs
- EAN code for a transport packaging
- 3838895703853
- Transport packaging weight
- 5.7 kg
- Transport packaging volume
- 9 dm³
- Pallet quantity
- 140 pcs
- Customs tariff
- 85362090
2 Diagrams
1 Software & drivers
Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
18 Tags
004672296Molded Case Circuit Breaker* EB2 400/4HLCD 250A 4p APGNSCETIBREAKMCCBEB2EB2electronicEB2 400InternationalMoulded case circuit breakers and disconnectors ETIBREAKCircuit breakers EB2 Series 20-1600ANumber of poles: 4Frame Size: 250AShort circuit capacity: 70 kA/70 kARated current: 250 A/250 ACatalogue Group: EB2Molded Case Circuit Breaker TOWAR Short circuit capacity: 70 kA/70 kA Rated current: 250 A/250 A Number of poles: 4 Catalogue Group: EB2 Frame Size: 250A
