002441632

ETITEC D 255/3 MINI Surge arrester

ETI Code:: 002441632
Function:: SPD
Surge arrester type:: T3
Uc Continous Operating Voltage AC:: 255 V
Nominal Discharge Current (8/20 μs) In:: 3 kA
Current type:: AC
Rated AC voltage:: 230 V
Up - Voltage Protection Level:: 17 kV
Leakage Current:: Yes
Network system:: TN-S
Installation:: Home and residental building protection
Built-in depth:: 35 mm
IP rating:: IP20
Applied Technology:: MOV, GDT
Catalogue Group:: ETITEC D

Product

EAN code for a single product: 3838895551584
Net weight of the product: 0.12 kg
Net width: 35 mm
Net height: 40 mm
Net depth: 11.57 mm
Stock unit of measure: pcs

Basic Packaging

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838895551584
Basic packaging weight: 0.012 kg
Basic Packaging Dimensions Height: 35 mm
Basic Packaging Dimensions Width: 25 mm
Basic Packaging Dimensions Depth: 11.5 mm
Basic packaging volume: 0.01 dm³

Transport Packaging

Transport packaging quantity: 30 pcs
EAN code for a transport packaging: 3838895551591
Transport packaging weight: 0.52 kg
Transport Packaging Dimensions Height: 305 mm
Transport Packaging Dimensions Width: 115 mm
Transport Packaging Dimensions Depth: 83 mm
Transport packaging volume: 2.911 dm³
Pallet quantity: 10,290 pcs
Customs tariff: 85363090

Max. conductor cross section flexible (fine-strand): 1.5 mm²
Nominal voltage AC: 230 V
Max. conductor cross section solid (solid, stranded): 1.5 mm²
Degree of protection (IP): IP20
Mounting method: Wall socket
Category type 3: Yes
Voltage protection level: 1.7 kV
Number of poles: 2
Voltage protection level L-PE/N-PE: 1.7 kV
Signalling at the device: Acoustic
Max. continuous voltage AC: 255 V
With remote signalling contact: Yes
Total discharge current (8/20) (L+N-PE): 3 kA
Nominal discharge surge current (8/20) (L-N): 3 kA

ETIM Classification – Version 9.0
