002444053
Obsolete
*ETITEC WENT TT 12,5/250 RC1+1 Surge arrester
- ETI Code:
- 002444053
- Function:
- SPD
- Surge arrester type:
- T1, T2
- Uc Continous Operating Voltage AC:
- 320 V
- Iimp(10/350) Impulse Current:
- 12.5 kA
- Nominal Discharge Current (8/20 μs) In:
- 25 kA
- Current type:
- AC
- Rated AC voltage:
- 230 V
- Up - Voltage Protection Level:
- 1.2 kV
- Remote signalisation:
- Yes
- Leakage Current:
- Yes
- Network system:
- TT/TN-S
- Number of modules:
- 2
- Installation:
- Home and residental building protection
- IP rating:
- IP20
- Applied Technology:
- MOV
- Catalogue Group:
- ETITEC WENT
2 Documents
8 Logistics
Product
- Net weight of the product
- 245 g
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 1 pcs
- EAN code for a transport packaging
- 3838895497417
- Transport packaging weight
- 3.5 kg
- Transport packaging volume
- 2.8 dm³
- Pallet quantity
- 229 pcs
- Customs tariff
- 85363090
14 ETIM
- Max. conductor cross section flexible (fine-strand)
- 25 mm²
- Remote signalling
- Yes
- Nominal voltage AC
- 230 V
- Max. conductor cross section solid (solid, stranded)
- 35 mm²
- Test class
- Type 1 + 2
- Mounting method
- DIN rail (top hat rail) 35 mm
- Lightning impulse current (10/350 µs)
- 12.5 kA
- Specific energy (W/R)
- 39 kJ/Ohm
- System configuration TN-S
- Yes
- Voltage protection level
- 1.2 kV
- Number of poles
- 2
- System configuration TT
- Yes
- Signalling at the device
- Optical
- Max. continuous voltage AC
- 320 V
ETIM Classification – Version 9.0
