002442334
Obsolete
*ETITEC A 500/15/C-0 Surge arrester
- ETI Code:
- 002442334
- Function:
- SPD
- Surge arrester type:
- A
- Uc Continous Operating Voltage AC:
- 500 V
- Terminal type:
- One-sided piercing
- Nominal Discharge Current (8/20 μs) In:
- 15 kA
- Current type:
- AC
- Rated AC voltage:
- 230 V
- Network system:
- TN
- Leakage Current:
- Yes
- Installation:
- Overhead line protection
- Applied Technology:
- MOV
- Catalogue Group:
- ETITEC A
1 Documents
2 Logistics
Product
- Stock unit of measure
- pcs
Transport Packaging
- Customs tariff
- 85354000
11 ETIM
- System configuration TN-C
- Yes
- Max. discharge surge current (8/20)
- 40 kA
- Nominal voltage AC
- 230 V
- Mounting method
- Direct mounting
- Construction size
- Other
- System configuration TN-S
- Yes
- System configuration TN
- Yes
- Signalling at the device
- Optical
- Category type 2
- Yes
- Max. continuous voltage AC
- 500 V
- Nominal discharge surge current (8/20)
- 15 kA
ETIM Classification – Version 9.0
