002442414
Obsolete
*ETITEC A 660/5/C-0 Surge arrester
- ETI Code:
- 002442414
- Function:
- SPD
- Surge arrester type:
- A
- Uc Continous Operating Voltage AC:
- 660 V
- Terminal type:
- One-sided piercing
- Nominal Discharge Current (8/20 μs) In:
- 5 kA
- Current type:
- AC
- Rated AC voltage:
- 230 V
- Network system:
- TN
- Leakage Current:
- Yes
- Installation:
- Overhead line protection
- Applied Technology:
- MOV
- Catalogue Group:
- ETITEC A
1 Documents
9 Logistics
Product
- Net weight of the product
- 0.15 kg
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 1 pcs
- EAN code for a basic packaging
- 3838895223436
- Basic packaging weight
- 0.226 kg
- Basic packaging volume
- 0.27 dm³
Transport Packaging
- Transport packaging quantity
- 24 pcs
- EAN code for a transport packaging
- 5904723002615
- Customs tariff
- 85363090
13 ETIM
- System configuration TN-C
- Yes
- Max. discharge surge current (8/20)
- 40 kA
- Number of conductors (without earthing)
- 1
- Nominal voltage AC
- 230 V
- Mounting method
- Direct mounting
- Construction size
- Other
- System configuration TN-S
- Yes
- Voltage protection level
- 2 kV
- System configuration TN
- Yes
- Signalling at the device
- Optical
- Category type 2
- Yes
- Max. continuous voltage AC
- 660 V
- Nominal discharge surge current (8/20)
- 5 kA
ETIM Classification – Version 9.0
