002443319
Obsolete
*ETITEC A 500/5/G-O Surge arrester
- ETI Code:
- 002443319
- Function:
- SPD
- Surge arrester type:
- A
- Uc Continous Operating Voltage AC:
- 500 V
- Terminal type:
- Clamp for transformers
- Nominal Discharge Current (8/20 μs) In:
- 5 kA
- Current type:
- AC
- Leakage Current:
- Yes
- Installation:
- Home and residental building protection
- Catalogue Group:
- ETITEC A
1 Documents
3 Logistics
Product
- Net weight of the product
- 0.15 kg
- Stock unit of measure
- pcs
Transport Packaging
- Customs tariff
- 85354000
10 ETIM
- System configuration TN-C
- Yes
- Nominal voltage AC
- 230 V
- Mounting method
- Direct mounting
- Construction size
- Other
- System configuration TN-S
- Yes
- System configuration TN
- Yes
- Signalling at the device
- Optical
- Category type 2
- Yes
- Max. continuous voltage AC
- 500 V
- Nominal discharge surge current (8/20)
- 5 kA
ETIM Classification – Version 9.0
