003801853
TR 1f 0-12V 50VA TH Transformer
- ETI Code:
- 003801853
- Catalogue Group:
- Single phase safety transformers for DIN rail
- IP rating:
- IP20
- No. Of Phases:
- Single
- Power:
- 50 VA
- Primary voltage Up:
- 230/400 V
- Secondary voltage Us:
- 12 V
4 Documents
14 Logistics
Product
- Net weight of the product
- 1.4 kg
- Net width
- 90 mm
- Net height
- 96 mm
- Net depth
- 106 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 1 pcs
- EAN code for a transport packaging
- 3838895480266
- Transport packaging weight
- 1.4 kg
- Transport Packaging Dimensions Height
- 90 mm
- Transport Packaging Dimensions Width
- 96 mm
- Transport Packaging Dimensions Depth
- 106 mm
- Transport packaging volume
- 1 dm³
- Pallet quantity
- 533 pcs
- Customs tariff
- 85043180
10 ETIM
- Built as safety transformer
- Yes
- Degree of protection (IP)
- IP20
- Rated apparent power
- 50 VA
- Type of insulation material according to IEC 85
- B
- Primary voltage 1(Min)
- 230 V
- Secondary voltage 1(Min)
- 12 V
- Primary voltage 2(Min)
- 400 V
- Primary voltage 2(Max)
- 400 V
- Secondary voltage 1(Max)
- 12 V
- Primary voltage 1(Max)
- 230 V
ETIM Classification – Version 9.0
