001696017
CM-60/630/3 Connection adapter
- ETI Code:
- 001696017
- Function:
- Connecting module
- Rated current:
- 630 A
- Number of poles:
- 3
- Rated cross section:
- 70-300 mm²
14 Logistics
Product
- Net weight of the product
- 1.026 kg
- Net width
- 144 mm
- Net height
- 208.5 mm
- Net depth
- 117.5 mm
- Stock unit of measure
- pcs
Transport Packaging
- Transport packaging quantity
- 1 pcs
- EAN code for a transport packaging
- 4029155917526
- Transport packaging weight
- 1.121 kg
- Transport Packaging Dimensions Height
- 220 mm
- Transport Packaging Dimensions Width
- 153 mm
- Transport Packaging Dimensions Depth
- 139 mm
- Transport packaging volume
- 4.679 dm³
- Pallet quantity
- 175 pcs
- Customs tariff
- 85369010
1 ETIM
- Type of accessory/spare part
- Other
ETIM Classification – Version 9.0
1 Software & drivers
Software is provided as is without any guarantees or warranty. The author is under no obligation to provide support, service, corrections, or upgrades to the free software programs or drivers.
17 Tags
001696017Connection adapterCM-60/630/3ETIBUSBAR60 mm busbar systemSupports and connectionsSupports and connectionsSupports and connectionsSupports and connectionsInternational60 mm busbar system ETIBUSBARSupport and connectionsFunction: Connecting moduleNumber of poles: 3Rated cross section: 70 mm²-300 mm²Rated current: 630 A/630 AConnection adapter Function: Connecting module Rated current: 630 A/630 A Number of poles: 3 Rated cross section: 70 mm²-300 mm²
