Fuse link D01 gG 2A/400V 002211001

Specifications

ETI Code:
002211001
Description:
D01 gG 2A/400V
Class name:
Fuse link
efuse:
1
Rated current (A):
2
Size:
D01
Type:
D0
Rated AC voltage (V):
400
Rated DC voltage (V):
250
Characteristics:
gG
Breaking capacity AC (kA):
50
Breaking capacity DC (kA):
8
Application:
For cable protection
Dimensions:
E14
Indicator:
Top fuse status indicator
Power dissipation (W):
2,1
Operating joule integral (A2s):
11,9
Prearcing joule integral (A2s):
1,2
Standards:
DIN EN 60269-1, DIN EN 60269-3

Documents

Product

EAN code for a single product
3838895905622
Net weight of the product
5.9  g
Customs tariff
85361010
logis_net_width
11  mm
logis_net_height
11  mm
logis_net_depth
36  mm

Level 1 Packaging

Basic packaging quantity
10
EAN code for a basic packaging
3838895000488
Basic packaging weight
0.06  kg

Level 2 Packaging

Transport packaging quantity
500
EAN code for a transport packaging
3838895162438
Transport packaging weight
3.33  kg
Pallet quantity
85000
Classification
EC001642
Class name
D0-system fuse link
Application
For cable protection
Rated voltage DC
250
Breaking capacity
50
Type of fuse status indicator
Top fuse status indicator
Max. rated operation voltage Ue AC
400
Construction size
D01
Rated current
2A
Rated voltage
400V
Colour code
Pink
Utilization category
Other
ETIM Classification – Version 7.0
