Modular contactor R 40-20 24V 002463491
Specifications
- ETI Code:
- 002463491
- Description:
- R 40-20 24V
- Class name:
- Modular contactor
- Function:
- Modular contactor
- Rated operational current Ie AC-1/AC-7 (A):
- 40A
- Rated operational voltage AC (V):
- 440V
- Rated AC control circuit voltage Uc (V):
- 24V
- Type:
- AC
- Rated Frequency (Hz):
- 50Hz/60Hz
- Number of NO contacts:
- 2
Documents
Logistic Data
Product
- EAN code for a single product
- 5902047612787
- Net weight of the product
- 0.24 kg
- Customs tariff
- 85364900
- logis_net_width
- 35 mm
- logis_net_height
- 88 mm
- logis_net_depth
- 65 mm
Basic packaging
- Basic packaging quantity
- 6
- EAN code for a basic packaging
- 3838895814917
- Basic packaging weight
- 1.44 kg
Transport packaging
- Transport packaging quantity
- 60
- EAN code for a transport packaging
- 3838895814924
- Transport packaging weight
- 14.65 kg
- Pallet quantity
- 3000
ETIM Clasification
- Classification
- EC001653
- Class name
- Installation contactor for distribution board
- Rated operating voltage
- 230…400V
- Rated operation current
- 40A
- Rated excitation voltage
- 230…400V
- Voltage type (operating voltage)
- AC
- Voltage type (excitation voltage)
- AC
- Number of contacts as normally open contact
- 2
- Slider for hand switch
- No
- Number of modular spacings
- 2
- Built-in depth
- 60mm
- Additional equipment possible
- Yes
- Degree of protection (IP)
- IP20
R 40-20 24V
