002464079
RA 40-20 230V AC Modular contactor
- ETI Code:
- 002464079
- Residual current type:
- AC
- Type description:
- AC
- Rated operational current Ie AC-1/AC-7:
- 40 A
- Rated operational voltage (AC):
- 440 V
- Rated control circuit voltage Uc (AC):
- 230 V
- Current type:
- AC
- Rated frequency:
- 50/60 Hz
- No. of NO contacts:
- 2
- Category:
- RA
4 Documents
22 Logistics
Product
- EAN code for a single product
- 3838400166692
- Net weight of the product
- 0.25 kg
- Net width
- 35 mm
- Net height
- 88 mm
- Net depth
- 65 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 5 pcs
- EAN code for a basic packaging
- 3838400092861
- Basic packaging weight
- 0.74 kg
- Basic Packaging Dimensions Height
- 67 mm
- Basic Packaging Dimensions Width
- 86 mm
- Basic Packaging Dimensions Depth
- 108 mm
- Basic packaging volume
- 0.622 dm³
Transport Packaging
- Transport packaging quantity
- 75 pcs
- EAN code for a transport packaging
- 3838400092878
- Transport packaging weight
- 18.8 kg
- Transport Packaging Dimensions Height
- 240 mm
- Transport Packaging Dimensions Width
- 230 mm
- Transport Packaging Dimensions Depth
- 390 mm
- Transport packaging volume
- 21.528 dm³
- Pallet quantity
- 2,325 pcs
- Customs tariff
- 85364900
22 Tags
002464079Modular contactorRA 40-20 230V ACETICONModular contactorsType-R2p, 2-modules40 A40 AInternationalContactors ETICONModular Contactors for installation into distribution boards and accesoriesModular Contactors for instalation into distribution boardsNo. of NC contacts: 0Rated operational voltage (AC): 440 VRated operational current Ie AC-1/AC-7: 40 ARated control circuit voltage Uc (AC): 230 VCurrent type: ACNo. of NO contacts: 2Category: RARated Frequency: 50 Hz/60 HzModular contactor Rated operational current Ie AC-1/AC-7: 40 A Rated control circuit voltage Uc (AC): 230 V Current type: AC No. of NO contacts: 2 No. of NC contacts: 0
