Memory relay WB-1UN 002471514
Specifications
- ETI Code:
- 002471514
- Description:
- WB-1UN
- Class name:
- Memory relay
- Mounting type:
- TH 35
Documents
Logistic Data
Product
- Net weight of the product
- 0.067 kg
- Customs tariff
- 85364900
Basic packaging
- Basic packaging quantity
- 1
- EAN code for a basic packaging
- 3838895722175
- Basic packaging weight
- 0.067 kg
Transport packaging
- Transport packaging quantity
- 12
- EAN code for a transport packaging
- 3838895792369
- Transport packaging weight
- 0.7 kg
- Pallet quantity
- 4800
Intermediate packaging
- qty
- 10 pcs
- Weight
- 0.67 kg
- volume
- 1.2 dm3
ETIM Clasification
- Classification
- EC001669
- Class name
- Timer relay for distribution board
- Type of excitation
- Analogue with single function
- Function
- Passing break contact
- Mounting method
- DIN rail
- Width in number of modular spacings
- 1
- Built-in height
- 65mm
- Number of changeover switches
- 1
- Supply voltage
- 230…230V
- Voltage type (supply voltage)
- AC
- Nominal switching current at 250 V AC
- 16A
WB-1UN
