002440742

Image of MOD. SM T12 PV 300/6,25 S

MOD. SM T12 PV 300/6,25 S Surge arrester

ETI Code:: 002440742
Function:: SPD Module
Network system:: DC
Catalogue Group:: ETITEC SM PV
Installation:: PV protection
IP rating:: IP20
Leakage Current:: No
Applied Technology:: MOV, GDT
Built-in depth:: 572 mm
Surge arrester type:: T1, T2
Uc Continous Operating Voltage DC:: 300 V
To use with:: ETITEC SM T12 PV
Current type:: DC
Iimp(10/350) Impulse Current:: 6.25 kA
Nominal Discharge Current (8/20 μs) In:: 20 kA

Technical data catalog

Product

Net weight of the product: 0.043 kg
Stock unit of measure: pcs

Basic Packaging

Basic packaging quantity: 1 pcs
EAN code for a basic packaging: 3838400000675
Basic packaging weight: 0.05 kg
Basic Packaging Dimensions Height: 99 mm
Basic Packaging Dimensions Width: 24 mm
Basic Packaging Dimensions Depth: 50 mm
Basic packaging volume: 0.119 dm³

Transport Packaging

Transport packaging quantity: 24 pcs
EAN code for a transport packaging: 3838400000699
Transport packaging weight: 1.281 kg
Transport Packaging Dimensions Height: 83 mm
Transport Packaging Dimensions Width: 305 mm
Transport Packaging Dimensions Depth: 116 mm
Transport packaging volume: 2.937 dm³
Pallet quantity: 8,160 pcs
Customs tariff: 85363090

Max. continuous voltage DC: 300 V
Test class: Type 1 + 2
Degree of protection (IP): IP20
Mounting method: On basic element
Construction size: 1 modular spacing
Lightning impulse current (10/350 µs): 6.25 kA
Number of poles: 1
Signalling at the device: Optical
System configuration DC: Yes

ETIM Classification – Version 9.0
