002440522
MOD. M T12 PV 750/6,25 S Surge arrester
- ETI Code:
- 002440522
- Function:
- SPD Module
- Network system:
- DC
- Catalogue Group:
- ETITEC M PV
- Installation:
- PV protection
- IP rating:
- IP20
- Leakage Current:
- Yes
- Applied Technology:
- MOV
- Built-in depth:
- 73.5 mm
- Surge arrester type:
- T1, T2
- Uc Continous Operating Voltage DC:
- 750 V
- To use with:
- ETITEC M T12 PV
- Current type:
- DC
- Iimp(10/350) Impulse Current:
- 6.25 kA
- Nominal Discharge Current (8/20 μs) In:
- 20 kA
- Max. Discharge current Imax, 8/20:
- 60 kA
5 Documents
21 Logistics
Product
- Net weight of the product
- 0.13 kg
- Net width
- 18 mm
- Net height
- 45 mm
- Net depth
- 82.14 mm
- Stock unit of measure
- pcs
Basic Packaging
- Basic packaging quantity
- 1 pcs
- EAN code for a basic packaging
- 3838895839552
- Basic packaging weight
- 0.096 kg
- Basic Packaging Dimensions Height
- 99 mm
- Basic Packaging Dimensions Width
- 24 mm
- Basic Packaging Dimensions Depth
- 50 mm
- Basic packaging volume
- 0.119 dm³
Transport Packaging
- Transport packaging quantity
- 28 pcs
- EAN code for a transport packaging
- 3838895839569
- Transport packaging weight
- 2.769 kg
- Transport Packaging Dimensions Height
- 109 mm
- Transport Packaging Dimensions Width
- 352 mm
- Transport Packaging Dimensions Depth
- 115 mm
- Transport packaging volume
- 4.412 dm³
- Pallet quantity
- 6,328 pcs
- Customs tariff
- 85363090
9 ETIM
- Max. continuous voltage DC
- 750 V
- Test class
- Type 1 + 2
- Degree of protection (IP)
- IP20
- Mounting method
- On basic element
- Construction size
- 1 modular spacing
- Lightning impulse current (10/350 µs)
- 6.25 kA
- Number of poles
- 1
- Signalling at the device
- Optical
- System configuration DC
- Yes
ETIM Classification – Version 9.0
